CBR Mould

California Bearing Ratio (CBR) Mould

Standard: ASTM D 1883, AASHTO T 193
Use: CBR Mould are used in California Bearing Ration Apparatus

Specification:

CBR Moulds are made from Gun Metal / Brass and are available with perforated base plate and extension collor.

California Bearing Ratio Apparatus (ASTM Version Mould) Standard: ASTM D 1883 AASHTO T 193 The assembly consist of the following:
Product Code	Specifications
ZI 3072-1	CBR Mould body complete with collor & perforated base plate. Plated steel 6 In. (152.4mm) Dia x 7 In. (177.8 mm) height
California Bearing Ratio Apparatus (BS Version Mould) Standard: BS 1377-4 The assembly consist of the following:
Product Code	Specifications
ZI 3073-1	CBR Mould body plated steel, with both ends threaded to fit the base or collar, 152 mm Dia x 127 mm hight.
